OPWILL OTN Transport Test Modules



2.7G OTM2511 SDH/SONET/OTN transport test module

supports 2.7G PDH/SDH/SONET/OTN test functionalities and offer comprehensive test solutions for metro network. It is a high cost-effective network test product.

Highlights

  • Offer test functions from PDH/DSn 1.5M to 2.5G/10G SDH/SONET/OTN in a single-slot module
  • Automatic signal structure discovery in smartmode, automatically detect and monitor error paths
  • Intuitionistic user interface, fast configuration of signal paths
  • Customizable various forms of test report

Applications

  • Support OTU1(2.7Gbit/s optical interface test
  • OTN testing at the OTU1 level including FEC as per ITU-T G.709

Key Features

  • Support OTU1(2.7Gbit/s) optical interface test
  • BERT and FEC analysis of OTU1/OTU2 according to ITU-T G.709 frames
  • Round-trip delay measurements
  • Independent transmitter and receiver testing
  • OTN alarm generation and monitoring
  • OTN overhead manipulation and capture
  • Frequency analysis and power measurement
  • Frequency offset generation
  • Automatic protection switching and service disruption time measurements
  • Support change overhead or insert alarm and error in high through mode



10.7G  OTM2512 SDH/SONET/OTN transport test module

supports 10.7G PDH/SDH/SONET/OTN test functionalities and offer comprehensive test solutions for metro network. It is a high cost-effective network test product.

Highlights

  • Offer test functions from PDH/DSn 1.5M to 2.5G/10G SDH/SONET/OTN in a dual-slot module
  • Automatic signal structure discovery in smartmode, automatically detect and monitor error paths
  • Intuitionistic user interface, fast configuration of signal paths
  • Customizable various forms of test report

Applications

  • Support OTU1(2.7Gbit/s)/OTU2(10.7Gbit/s) optical interface test
  • OTN testing at the OTU1 and OTU2 level including FEC as per ITU-T G.709

Key Features

  • Support OTU1(2.7Gbit/s)/OTU2(10.7Gbit/s) optical interface test
  • BERT and FEC analysis of OTU1/OTU2 according to ITU-T G.709 frames
  • Round-trip delay measurements
  • Independent transmitter and receiver testing
  • OTN alarm generation and monitoring
  • OTN overhead manipulation and capture
  • Frequency analysis and power measurement
  • Frequency offset generation
  • Automatic protection switching and service disruption time measurements
  • Support change overhead or insert alarm and error in high through mode



OTM2540 43G OTN transport test module

is one of OPWILL’s modular test products. OTM2540 can be configured on OTP6800 test platforms to achieve TN test functionalities and offer comprehensive test solutions for metro network. It is a high cost-effective network test product.

Highlights

  • Offer 43G SDH/SONET/OTN test functions
  • FEC capability analysis and ODU multiplex test of OTU3 optical signal as per ITU-T G.709
  • Automatic signal structure discovery in smartmode, automatically detect and monitor error paths
  • Intuitionistic user interface, fast configuration of signal paths
  • Customizable various forms of test report

Applications

OTN testing at the OTU3 level including FEC as per ITU-T G.709

Key Features

  • Support OTU3 (43Gbit/s) optical interface relative test
  • BERT and FEC analysis of OTU3 according to ITU-T G.709 frames
  • 2.5G/10G SDH/SONET signal synchronous/asynchronous mapping and demapping in OTN
  • Round-trip delay measurements
  • Independent transmitter and receiver testing
  • OTN alarm generation and monitoring
  • OTN overhead manipulation and capture
  • Frequency analysis and power measurement
  • Frequency offset generation
  • Automatic protection switching and service disruption time measurements
  • Senior through mode measurement
