9200 Series

Multi-Range Programmable DC Power Supplies
Model 9201

Multi-Range Programmable DC Power Supplies
Model 9202

Multi-Range Programmable DC Power Supplies
Model 9205

Multi-Range Programmable DC Power Supplies
Model 9206

Any 9200 series model can replace several supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, these multi-range power supplies automatically recalculate voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.

For benchtop applications, these power supplies provide a numerical keypad for direct data entry along with convenient cursors and analog style knobs to quickly make incremental voltage or current changes. System integrators benefit from the standard USB (USBTMC-compliant), RS-232, and GPIB interfaces supporting SCPI commands.

• Multi-ranging operation
• High programming and readback resolution of 1 mV/0.1 mA
• Output timer function
• List mode programming
• Store and recall up to 72 instrument settings
• Standard USB (USBTMC-compliant), RS-232, and GPIB interfaces supporting SCPI commands for remote control
• Remote sense
• Overvoltage protection (OVP), overpower protection (OPP), overtemperature protection (OTP), and key-lock function
• NI-certified LabVIEW driver and softpanel for remote control, test sequence generation, and datalogging available
• Compact 19" half-rack form factor allows for side-by-side rack mounting of two units
