The PicoScope 4824 is a low-cost, portable solution for multi-input applications. With 8 high-resolution analog channels you can easily analyze audio, ultrasound, vibration, power, and timing of complex systems.
Despite its compact size, there is no compromise on performance. With a high 12-bit vertical resolution, bandwidth of 20 MHz, 256 MS buffer memory, and a fast sampling rate of 80 MS/s, the PicoScope 4824 has the power and functionality to deliver accurate results. It also features deep memory to analyze multiple serial buses such as UART, I2C, SPI, CAN and LIN plus control and driver signals.
PicoScope software dedicates almost all of the display area to the waveform. Using the display of your laptop or desktop the area is much bigger and of a higher resolution than with a traditional benchtop scope. This is a huge advantage when displaying eight high-resolution channels.
With a large display area available, you can also create a customizable split-screen display, and view multiple channels or different views of the same signal at the same time. As the example opposite shows, the software can even show both oscilloscope and spectrum analyzer traces at once. Additionally, each waveform shown works with individual zoom, pan, and filter settings for ultimate flexibility.
The PicoScope software can be controlled by mouse, touchscreen or keyboard shortcuts.
The PicoScope 4824 is a 12-bit oscilloscope that offers 16 times more vertical resolution than traditional 8-bit oscilloscopes (4096 vertical levels vs 256). The example shows how with a 12-bit oscilloscope (blue trace) you can zoom in to reveal details of the signal that are not visible on an 8-bit oscilloscope (black trace).
As well as the high vertical resolution, the 256 million sample buffer memory ensures a high horizontal resolution as well. You can collect long detailed captures without the sampling rate dropping.
Once you have seen high-resolution waveforms on a high-resolution PC monitor you will never want to use a traditional benchtop oscilloscope with its small display again.
As well as improved oscilloscope traces, high resolution offers big benefits when performing spectrum analysis offering an additional 20 dB dynamic range on the spectrum over 8-bit oscilloscopes. Signals that were previously hidden in the noise floor are now clearly visible and the spectrum becomes a powerful tool to track down the causes of noise.
The PicoScope 4824 mix of 8 channels, high resolution and deep memory makes it suitable for a wide range of applications that cannot be met by traditional benchtop oscilloscopes.
8 channels allows multiple power supply rails to be monitored at the same time, ideal for looking at power supply sequencing, balancing or quality. The high channel count allows the decoding of multiple different serial bus standards at the same time (CAN, LIN, FlexRay, I2C, SPI etc.)
12 bit resolution both for the oscilloscope and spectrum analyzer helps track down noise, analyze harmonics and measure distortion.
The 256 MS deep memory allows several seconds of capture at the full sampling rate (ideal for long captures of serial data or looking for glitches in power supplies). Managing all this data calls for some powerful tools, so zoom factors of several million are possible. Other tools such as the waveform buffer, mask limit test, serial decode and hardware acceleration work with the deep memory making the PicoScope 4824 one of the most powerful oscilloscopes on the market.
The compact size takes up little space on the bench and USB power makes the PicoScope 4824 ideal for those on the move. For the first time you can carry an 8 channel oscilloscope in your laptop bag!
